Temperature Sensor
Operation range:*
-20° to 70°C (-4° to 158°F) in air;
maximum sustained temperature of 30°C (86°F) in water*
Accuracy: 0.2°C over 0° to 50°C (0.36°F over 32° to 122°F)
Resolution: 0.02°C at 25°C (0.04°F at 77°F)
Response time: 5 minutes in water; 12 minutes in air moving 2 m/sec; 20 minutes in air moving 1 m/sec (typical to 90%)
Stability (drift): 0.1°C (0.18°F) per year
Logger
Real-time clock: ± 1 minute per month 0° to 50°C (32° to 122°F)
Battery: 3 Volt lithium, non-replaceable
Battery life (typical use): 5 years with 1 minute or greater logging interval
Memory (non-volatile): 64K bytes memory (approx. 42,000 12-bit temperature measurements)
Weight: 19.6 g (0.69 oz)
Dimensions: 3.0 × 4.1 × 1.7 cm (1.2 × 1.6 × 0.68 in.); mounting bail 4.6 mm (3/16 in.) diameter hole
Wetted materials: Epoxy case
Waterproof: To 305 m (1000 ft.)
Logging
interval: Fixed-rate or multiple logging intervals, with up to 8
user-defined logging intervals and durations; logging intervals from 1
second to 18 hours. Refer to HOBOware software manual.
Launch modes: Immediate start, delayed start
Offload modes: Offload while logging; stop and offload
Battery
indication: Battery level can be viewed in status screen and optionally
logged in datafile. Low battery indication in datafile.
NIST certificate: Available for additional charge
The CE Marking identifies this product as complying with the relevant directives in the European Union (EU).
* To guarantee accuracy, the TidbiT v2 Temp must not be used in
condensing environments and water temperatures higher than 30C (86F) for
more
than eight cumulative weeks over the life of the logger. Frequent or
prolonged exposure will lead to measurement drift and eventual failure.
